Asus GeForce RTX 4070 Dual OC 12GB

Photos - Graphics Card Asus GeForce RTX 4070 Dual OC 12GB
Videos 2Photos 15
Outdated Product
33 222

Relatively compact, pre-top level graphics card based on the progressive NVIDIA Ada Lovelace graphics microarchitecture, introduced at the end of 2022. Against the background of its fellows in the series, it differs in compact dimensions: the GPU is dressed in a 200 mm long case that occupies only 2 motherboard slots, so it will fit into a miniature Cube Case or similar case without any problems. A dual-slot heatpipe cooling system with Axial-tech fans with extended blades ensures efficient heat dissipation from the card. A strong aluminium plate on the back of the model prevents the PCB from bending. In the NVIDIA hierarchy, the card occupies an intermediate position, significantly outperforming the younger RTX 4050/4060 GPUs, but at the same time noticeably inferior in performance to the...extremely powerful and expensive RTX 4080/4090, which NVIDIA positions as professional tools. It is an optimal replacement for three- or four-year-old mid-range graphics cards. The heart of the Asus GeForce RTX 4070 Dual OC 12GB GDDR6X is the AD 104 GPU. The card is made using a 5nm process technology and operates in a frequency range up to 2550 MHz. GPU support is immediately provided by 12 GB of GDDR6X memory with an operating frequency of 21000 MHz and a 192-bit data exchange bus. There are advanced ray tracing and third and fourth generation tensor cores that are responsible for hardware ray tracing and intelligent DLSS scaling. DLSS 3.0 uses a new data type (optical flow field), which improves the efficiency of drawing algorithms and the quality of the output material. This technology is only available on the latest NVIDIA graphics cards, previous generations do not support it. Well, the new RT cores handle lighting and shadows in games more realistically. The overall performance of the RTX 4070 has increased by 45% compared to its predecessor RTX 3070, coming close to the RTX 3080. In general, the model is able to maintain a comfortable frame rate at high or maximum graphics settings in all AAA games of recent years in Full HD or 2K resolution. With a further increase in resolution, the player will have to significantly reduce the graphic settings and actively use DLSS.
add to listmy lists
Asus GeForce RTX 4070 Dual OC 12GB
12 GB / 2505 MHz
12 GB / 2550 MHz
Main
InterfacePCI-E v4.0
GPU
Model GPUNVIDIA GeForce RTX 4070
ArchitectureAda Lovelace
Memory size12 GB
Memory typeGDDR6X
Memory bus192 bit
GPU clock speed2550 MHz
Memory clock21000 MHz
Lithography5 nm
Max. resolution7680x4320 px
Connections
HDMI1
HDMI versionv.2.1
DisplayPort3
DisplayPort versionv.1.4a
Software
DirectX12 Ultimate
OpenGL4.6
Stream processors5888
Passmark G3D Mark26394 score(s)
General
Monitors connection4
Coolingactive (fan)
Fans2
Additional power8 pin
Minimum PSU recommendation650 W
Number of slots2.5
Length267 mm / 267x134x51 /
Official Websiteasus.com
Added to E-CatalogApril 2023
P/N
90YV0IZ2-M0NA00

DUAL-RTX4070-O12G

Relatively compact, pre-top level graphics card based on the progressive NVIDIA Ada Lovelace graphics microarchitecture, introduced at the end of 2022. Against the background of its fellows in the series, it differs in compact dimensions: the GPU is dressed in a 200 mm long case that occupies only 2 motherboard slots, so it will fit into a miniature Cube Case or similar case without any problems.

A dual-slot heatpipe cooling system with Axial-tech fans with extended blades ensures efficient heat dissipation from the card. A strong aluminium plate on the back of the model prevents the PCB from bending. In the NVIDIA hierarchy, the card occupies an intermediate position, significantly outperforming the younger RTX 4050/4060 GPUs, but at the same time noticeably inferior in performance to the extremely powerful and expensive RTX 4080/4090, which NVIDIA positions as professional tools.

It is an optimal replacement for three- or four-year-old mid-range graphics cards. The heart of the Asus GeForce RTX 4070 Dual OC 12GB GDDR6X is the AD 104 GPU. The card is made using a 5nm process technology and operates in a frequency range up to 2550 MHz. GPU support is immediately provided by 12 GB of GDDR6X memory with an operating frequency of 21000 MHz and a 192-bit data exchange bus.

There are advanced ray tracing and third and fourth generation tensor cores that are responsible for hardware ray tracing and intelligent DLSS scaling. DLSS 3.0 uses a new data type (optical flow field), which improves the efficiency of drawing algorithms and the quality of the output material. This technology is only available on the latest NVIDIA graphics cards, previous generations do not support it.

Well, the new RT cores handle lighting and shadows in games more realistically. The overall performance of the RTX 4070 has increased by 45% compared to its predecessor RTX 3070, coming close to the RTX 3080. In general, the model is able to maintain a comfortable frame rate at high or maximum graphics settings in all AAA games of recent years in Full HD or 2K resolution. With a further increase in resolution, the player will have to significantly reduce the graphic settings and actively use DLSS.

The information in the model description is for reference purposes.
Always clarify the specifications and configuration of the product with the online store manager before purchasing.
Catalog Asus 2025 - new arrivals, bestsellers, and the most relevant models Asus.

Asus GeForce RTX 4070 Dual OC 12GB price graph

  • Minimum
  • Average
  • Maximum
чудова модель, дуже сподобалося
 12 December 2024
дуже довго обирав відеокарту,перші погляди були на 4060,4060 ті бо вони дешевші,якщо з 4060 різниця майже 10к,але вдалося придбате саме цю середню відеокарту,ігри всі тягне,новенький сталкер,індіана джонсякщо не вмикати трасування шляху на повну,бо буде 5-10фпс в 1080р,спробував генерацію зображень,в цілому задоволений.
працює добре,доволі адекватна продуктивність.
розчарував більше не сам товар а його оглядачі які тестували температури чомусь у відкритих стендах а не у закритому корпусі,тож температура особливо влітку відрізнялась дуже65гпу 75 хотспот, а по факту 75-85гпу, і до 100 хотспотякщо в вас великий корпус то я думаю буде набагато краще з обдувом.
ну і трішки шиплять дросселі під навантаженням.
Antonuse Asus GeForce RTX 4070 Dual OC 12GB few months
miraculous model, already vouchsafed
 10 December 2024
Cool video card! Quiet, not hot, the maximum temperature I have seen is 61 degrees. Very productive, in 2k copes with high! I advise!
Silence, productivity
Mute
igor Shulginuse Asus GeForce RTX 4070 Dual 12GB less than month
I recommend!
 5 December 2024
Great video card for its price. At 1080p, everything works, well, it keeps stable at almost ultra 60 frames.
Price
Haven't noticed yet
DEUS DeadMorozuse Asus GeForce RTX 4070 Dual 12GB more than year
